15.0"_Innolux_G150XJE-E01
Resolution
1024 X 768
Brightness
400 cd/m2 (Typ.)
Viewing Angle
88/88/88/88 (Typ.)(CR>=10)
Contrast Ratio
2500:1 (Typ.) ( Transmission )
Display Colors
262k/16.7m 72% (CIE1931)
Pixel Format
RGB Vertical Stripe
Display Area
304.128 X 228.096(mm)
Display Mode
super mva， Normally Black ， Transmissive
Lamp Type
WLED 70k Hours With LED Driver
Outline Size
326.5 X 253.5 X 9.6(mm)
Surface
Matte ，Hard coating (3H)
Panel Weight
942/980g (Typ./max.)
Response Time
16/7 (Typ.)(tr/td) ms
Frequency
60Hz
Signal Interface
eDP 30 pins (1 lane)
Input Voltage
3.3v (Typ.)
Environment
Operating Temp.: -20 ~ 70°c; Storage Temp.: -30 ~ 70°c;
Current State
In Production
