G156XW01 V101
Resolution
1366 X 768
Brightness
400 (Typ.)
Viewing Angle
85/85/80/80 (Typ.)(CR>=10)
Contrast Ratio
500 : 1 (Typ.) ( Transmission )
Display Colors
16.7m 70% (CIE1931)
Pixel Format
RGB Vertical Stripe
Display Area
344.232 X 193.536(mm)
Display Mode
TN， Normally White ， Transmissive
Lamp Type
WLED 50k Hours With LED Driver
Outline Size
363.8 X 215.9 X 17.35(mm)
Surface
Matte ，Hard coating (3H)
Panel Weight
1.25/1.35kgs (Typ./max.)
Response Time
6/2 (Typ.)(tr/td) ms
Frequency
60Hz
Signal Interface
LVDS (1 ch 8-bit) 30 pins
Input Voltage
5.0v (Typ.)
Environment
Operating Temp.: 0 ~ 60°c; Storage Temp.: -20 ~ 60°c;
