15.0"_MITSUBISHI-AC150XA01
Resolution
1024 X 768
Brightness
450 cd/m2 (Typ.)
Viewing Angle
80/80/70/70 (Typ.)(CR>=10)
Contrast Ratio
700:1 (Typ.) ( Transmission )
Display Colors
262k/16.7m
Pixel Format
RGB Vertical Stripe
Display Area
304.128 X 228.096(mm)
Display Mode
TN， Normally White ， Transmissive
Lamp Type
WLED 100k Hours With LED Driver
Outline Size
326.5 X 253.5(mm)
Surface
Matte ，Hard coating (3H)
Panel Weight
1.05kgs (Typ.)
Response Time
2/10 (Typ.)(Tr/Td) ms
Frequency
60Hz
Signal Interface
LVDS 20 pins (1 ch 6/8-bit)
Input Voltage
3.3v (Typ.)
Environment
Operating Temp.: 0 ~ 65°c; Storage Temp.: -20 ~ 65°c;
