G156HTN02.1
Resolution
1920 X 1080
Brightness
400 cd/m2 (Typ.)
Viewing Angle
70/70/60/60 (Typ.)(CR>=10)
Contrast Ratio
500:1 (Typ.) ( Transmission )
Display Colors
16.7m 72% (CIE1931)
Pixel Format
RGB Vertical Stripe
Display Area
344.16 X 193.59(mm)
Display Mode
TN， Normally White ， Transmissive
Lamp Type
WLED 50k Hours With LED Driver
Outline Size
363.8 X 215.9 X 9.8(mm)
Surface
Matte (Haze 25%)，Hard coating (3H)
Panel Weight
tbd
Response Time
8 (Typ.)(Tr+Td) ms
Frequency
60Hz
Signal Interface
LVDS 30 pins (2 ch 8-bit)
Input Voltage
3.3v (Typ.)
Environment
Operating Temp.: -10 ~ 70°c; Storage Temp.: -20 ~ 70°c;
