| Item |
Specification |
| System Category |
LCD/OLED/EPD Panel Modules > TFT-LCM Liquid Crystal Modules |
| Product Brand |
HM |
| Product Model |
HM150GKS01F |
| Key Description |
15-inch, 450 nits Brightness, 1024*768 Resolution |
| Product Category |
Graphic Type |
| Product Labels |
Color TFT LCD Screen, Wide-Temperature LCD Screen, IPS LCD Screen |
| Application Products |
Digital Signage |
| Panel Type |
a-Si TFT-LCD |
| Product Composition |
Liquid Crystal Module |
| Panel Size |
15" |
| Resolution |
1024×768 |
| Aspect Ratio |
4:3 (Width:Height) |
| Physical Shape |
Flat Rectangle |
| Active Area (A.A) |
304.128 (W) × 228.096 (H) mm |
| Outline Dimension |
326.5 (W) × 253.5 (H) mm |
| Maximum Thickness |
9.7 mm |
| LCD Mode Family |
IPS Hard Panel |
| Polarizer |
Transmissive Type |
| Panel Brightness |
450 (Typ.) nits |
| Transmissive Contrast Ratio |
1200:1 (Typ.) |
| Viewing Angle |
89/89/89/89 (Left/Right/Up/Down) |
| Display Colors |
16.7M |
| Backlight Type |
WLED |
| Signal Type |
LVDS |
| Signal Pin Count |
20 Pins |
| Touch Screen |
None |
| Operating Temperature |
-20 ~ 70 °C |
| Storage Temperature |
-30 ~ 80 °C |
