15.0"_BOE_DV150X0M-N16
Resolution
1024 X 768
Brightness
600 cd/m2 (Typ.)
Viewing Angle
89/89/89/89 (Typ.)(CR>=10)
Contrast Ratio
1000:1 (Typ.) ( Transmission )
Display Colors
16.7m , 72% ntsc
Pixel Format
RGB Vertical Stripe
Display Area
304.128 X 228.096(mm)
Display Mode
ads， Normally Black ， Transmissive
Lamp Type
WLED [12s4p] , 50k Hours , With LED Driver
Outline Size
326.5 X 253.5 X 9.7(mm)
Surface
Matte (Haze 25%)，Hard coating (3H)
Panel Weight
730g
Response Time
30 (Typ.)(Tr+Td) ms
Frequency
60Hz
Signal Interface
LVDS 20 pins (1 ch, 8-bit) ,
Input Voltage
3.3v (Typ.)
Environment
Operating Temp.: -20 ~ 70°c; Storage Temp.: -20 ~ 70°c;
Current State
In Production
